SOL-524 T1+T2 16 A prefabricated AC RCD 3F Switchboard
Manufacturer: iONTEC
INDEX: SOL-524
The T1+T2 AC electrical switchgear provides full protection of DC circuits of a photovoltaic installation from the effects of surges. Its design is suitable for surface mounting.
The product consists of a housing, transparent door, TH-35 mm rails, N+PE terminals, front cover with cut-outs for apparatus, chokes, caps, and mounting parts.
Electrical and mechanical parameters of the enclosure:
- Designed for surface mounting
- Manufactured in accordance with EN 60670, EN 62208
- Rated current In 63 A
- IP65 rating
- Protection class II
- Rated insulation voltage Ui: 690 V AC, 1000 V DC
- Glow wire test: 650°C
- Impact resistance: IK08
- Operating temperature: -25°C to +60°C
- Halogen-free recyclable plastic
Overcurrent circuit breaker NOARK Ex9BN 3P:
- B curve
- Manufactured in accordance with IEC/EN 60898-1
- Rated short-circuit breaking capacity ICN: 6 kA
- Rated switching voltage 230/400 V AC
Residual-current circuit breaker Ex9L-N:
- Switch type: A
- Rated current: 40 A
- Rated residual current: 100 mA
- Number of poles: 4
- Short-circuit withstand capacity: 6 kA
AC NOARK Ex9UE1+2 12,5 4P 275 surge arrester:
- Maximum discharge current Ilim (10/350 us) per phase: 12,5 kA
- Continuous operating voltage Uc: 275 V per phase
- T1+T2 (Class I+II, Type 1+2, B+C)
- Size: 4 modules
| Switchboards: | 12 polowa |
|---|---|
| Weight [kg]: | 2.84 |
| Dimensions [mm]: | 320.0 x 280.0 x 160.0 |
| Residual current device: | Yes |
|---|---|
| Type of protection: | AC |
| Type of surge arrester AC: | T1+2 |
| Switchgear type: | Prefabricated |
| Max. current [A]: | 16 |
| Feed-in phases: | 3 |
