Solar Inverter Solarix PLI 5000-48 5kW Steca
Manufacturer: Steca
INDEX: 760.607
The STECA Solarix PLI grit-tied inverter with integrated charge controller is the first product from Steca Elektronik to offer an all-in-one package. It enables users to supply 230 V AC power to consumer units, charges the battery using the integrated MPPT charge controller, while providing connection to a generator or available mains.
Tracking the maximum power point in the integrated charge controller ensures that even in adverse weather conditions it is possible to obtain maximum energy from the photovoltaic modules to optimally charge the battery and simultaneously supply the consumer units.
Distinguishing features:
- Maximum efficiency 93%
- Input voltage range 90 to 280 V
- High overload capacity
- Ambient temperature range: -15°C to +60°C
- Multi-stage charging technology
- Wide range of security functions
- Can be combined in parallel or in three phases (parallel set required)
Operation and installation:
- Lightweight and easy to assemble and disassemble
- Adjustable cut-off voltages
- Auxiliary contact for starting the generator
- RS-232 serial interface to a computer
- IP21 rating
- Dimensions 298 x 469 x 130 mm
Use:
- Monitoring of power status and grid parameters on the display
- Clear graphical control panel with LCD display
- 3 multicolour LEDs displaying operating states
- 5-year warranty
| Max. efficiency [%]: | 93 |
|---|---|
| Communication type: | RS232 |
| Dimensions [mm]: | 395.0 x 590.0 x 210.0 |
| Input frequency [Hz]: | 40 - 65 |
|---|---|
| Input voltage DC [V] : | 48 |
| Input voltage range AC [V]: | 90 - 280 |
| Input voltage range DC [V]: | 38.4 - 66 |
| Power [W]: | 4800 |
| Feed-in phases: | 1 |
